This content pack contains four RPS Composites Autodesk® AutoCAD® Plant 3D Spec files. They are offered here to assist with the specification of FRP pipe and fittings, enabling end-users to have a much more accurate representation of FRP piping, instead of modeling in steel or some other stock library.

P-150 Belled Parts (our corrosion-resistant line with the broadest application)

P-150 Plain Parts

A-150 Belled Parts (our abrasion- and corrosion-resistant line)

A-150 Plain Parts

Please note that files for our H-150 high-temperature corrosion-resistant line are not specifically available here. However, as our A-150, P-150, and H-150 belled and plain parts have the same dimensions, the files are interchangeable. At the moment, the library only has P-150 and A-150. They are identical except in the BOM, where the name “A-150” will appear if you use the A-150 library, and “P-150” will appear if you use the P-150 library.

You might also want to access our RPS Design Manual, available here. (https://rpscomposites.com/company-literature/)
